Pilot operated pressure relief valve
PRM7
Details
- Catalog: 61411
- Size: ISO 4401-07
- Mounting Style: stackable
- Max Operating Pressure: 350 bar
- Max Flow: 300 l/min
Download
- Rendering 3D: 3D Model
- * Data sheets:
- Other languages:
- * Last update: DE (02/04/2025)
DESCRIPTION
The PRM7 valve is a pilot-operated pressure relief valve designed in a stackable modular configuration. It is available with pressure limitation on port P and discharge in T, offered in five different pressure regulation ranges to suit various hydraulic circuit requirements.
This valve is commonly used as a pressure limiting device within hydraulic circuits, ensuring reliable protection against overpressure.
The PRM7 comes supplied with a hexagon socket adjusting screw and a locking nut for secure and precise adjustment, or with an ergonomic knob for easier manual control.
