Stacked valve assembly
BD*
Details
- Catalog: 44101
- Mounting Style: stackable valve assembly
- Max Operating Pressure: 320 bar
- Max Flow: 60 l/min
Download
- Rendering 3D: 3D Model
- * Data sheets:
- Other languages:
- * Last update: DE (05/06/2024)
DESCRIPTION
BDL, BDM and BDS are components for stacked valve assemblies.
They can be assembled in parallel with up to 10 working sections. The same components allow creating series circuits by inserting plugs in order to deviate the oil path. Inlet elements are available with flow and pressure control, with and without unloading valves. Working elements are available in two thicknesses with working ports 3/8” BSP, 1/2” BSP, SAE-06 or SAE-08 threads.
Specific components for series circuits complete the BD* range.
DOWNLOAD 3D MODELS
At the service of our customers from the early design stages
Duplomatic offers the possibility to download 3D models of all products through a dedicated web portal.
How to use the service
Just go to the website https://duplomatic.partcommunity.com and register for free to configure and preview the desired model. Registration allows you to download our 3D models unlimited, choosing from the most common CAD formats. You can also generate and download a PDF containing an interactive 3D model and a summary of the technical data.
Click on the button below for the step by step registration and download guide.
Integration into your management system
That's not all. If you wish and your internal management software is able to, you can also download the entire catalogue and integrate it into your component database of all your projects.
Download: Step by step CADENAS ITA Download: Step by step CADENAS ENG
